Instance: hydroenergy1

Formats ams gms lp mod nl osil pip
Primal Bounds
209721.00660000 p1 ( gdx sol )
(infeas: 1e-12)
Dual Bounds
211181.11600000 (ANTIGONE)
209741.98080000 (BARON)
209899.68520000 (COUENNE)
211788.93720000 (LINDO)
209821.59930000 (SCIP)
References Castro, Pedro M, Hydro Energy System Scheduling, 2014.
Source MINLP_EX1.gms from minlp.org model 181
Application Hydro Energy System Scheduling
Added to library 12 Aug 2014
Problem type MBQCP
#Variables 288
#Binary Variables 96
#Integer Variables 0
#Nonlinear Variables 96
#Nonlinear Binary Variables 0
#Nonlinear Integer Variables 0
Objective Sense max
Objective type linear
Objective curvature linear
#Nonzeros in Objective 96
#Nonlinear Nonzeros in Objective 0
#Constraints 428
#Linear Constraints 380
#Quadratic Constraints 48
#Polynomial Constraints 0
#Signomial Constraints 0
#General Nonlinear Constraints 0
Operands in Gen. Nonlin. Functions
Constraints curvature indefinite
#Nonzeros in Jacobian 1116
#Nonlinear Nonzeros in Jacobian 120
#Nonzeros in (Upper-Left) Hessian of Lagrangian 144
#Nonzeros in Diagonal of Hessian of Lagrangian 0
#Blocks in Hessian of Lagrangian 24
Minimal blocksize in Hessian of Lagrangian 4
Maximal blocksize in Hessian of Lagrangian 4
Average blocksize in Hessian of Lagrangian 4.0
#Semicontinuities 0
#Nonlinear Semicontinuities 0
#SOS type 1 0
#SOS type 2 0
Infeasibility of initial point 5.475
Sparsity Jacobian Sparsity of Objective Gradient and Jacobian
Sparsity Hessian of Lagrangian Sparsity of Hessian of Lagrangian

$offlisting
*
*  Equation counts
*      Total        E        G        L        N        X        C        B
*        429       97      144      188        0        0        0        0
*
*  Variable counts
*                   x        b        i      s1s      s2s       sc       si
*      Total     cont   binary  integer     sos1     sos2    scont     sint
*        289      193       96        0        0        0        0        0
*  FX      2
*
*  Nonzero counts
*      Total    const       NL      DLL
*       1213     1093      120        0
*
*  Solve m using MINLP maximizing objvar;


Variables  b1,b2,b3,b4,b5,b6,b7,b8,b9,b10,b11,b12,b13,b14,b15,b16,b17,b18,b19
          ,b20,b21,b22,b23,b24,b25,b26,b27,b28,b29,b30,b31,b32,b33,b34,b35,b36
          ,b37,b38,b39,b40,b41,b42,b43,b44,b45,b46,b47,b48,b49,b50,b51,b52,b53
          ,b54,b55,b56,b57,b58,b59,b60,b61,b62,b63,b64,b65,b66,b67,b68,b69,b70
          ,b71,b72,b73,b74,b75,b76,b77,b78,b79,b80,b81,b82,b83,b84,b85,b86,b87
          ,b88,b89,b90,b91,b92,b93,b94,b95,b96,x97,x98,x99,x100,x101,x102,x103
          ,x104,x105,x106,x107,x108,x109,x110,x111,x112,x113,x114,x115,x116
          ,x117,x118,x119,x120,x121,x122,x123,x124,x125,x126,x127,x128,x129
          ,x130,x131,x132,x133,x134,x135,x136,x137,x138,x139,x140,x141,x142
          ,x143,x144,x145,x146,x147,x148,x149,x150,x151,x152,x153,x154,x155
          ,x156,x157,x158,x159,x160,x161,x162,x163,x164,x165,x166,x167,x168
          ,x169,x170,x171,x172,x173,x174,x175,x176,x177,x178,x179,x180,x181
          ,x182,x183,x184,x185,x186,x187,x188,x189,x190,x191,x192,x193,x194
          ,x195,x196,x197,x198,x199,x200,x201,x202,x203,x204,x205,x206,x207
          ,x208,x209,x210,x211,x212,x213,x214,x215,x216,x217,x218,x219,x220
          ,x221,x222,x223,x224,x225,x226,x227,x228,x229,x230,x231,x232,x233
          ,x234,x235,x236,x237,x238,x239,x240,x241,x242,x243,x244,x245,x246
          ,x247,x248,x249,x250,x251,x252,x253,x254,x255,x256,x257,x258,x259
          ,x260,x261,x262,x263,x264,x265,x266,x267,x268,x269,x270,x271,x272
          ,x273,x274,x275,x276,x277,x278,x279,x280,x281,x282,x283,x284,x285
          ,x286,x287,x288,objvar;

Positive Variables  x97,x98,x99,x100,x101,x102,x103,x104,x105,x106,x107,x108
          ,x109,x110,x111,x112,x113,x114,x115,x116,x117,x118,x119,x120,x121
          ,x122,x123,x124,x125,x126,x127,x128,x129,x130,x131,x132,x133,x134
          ,x135,x136,x137,x138,x139,x140,x141,x142,x143,x144,x145,x146,x147
          ,x148,x149,x150,x151,x152,x153,x154,x155,x156,x157,x158,x159,x160
          ,x161,x162,x163,x164,x165,x166,x167,x168,x169,x170,x171,x172,x173
          ,x174,x175,x176,x177,x178,x179,x180,x181,x182,x183,x184,x185,x186
          ,x187,x188,x189,x190,x191,x192,x193,x194,x195,x196,x197,x198,x199
          ,x200,x201,x202,x203,x204,x205,x206,x207,x208,x209,x210,x211,x212
          ,x213,x214,x215,x216,x217,x218,x219,x220,x221,x222,x223,x224,x225
          ,x226,x227,x228,x229,x230,x231,x232,x233,x234,x235,x236,x237,x238
          ,x239,x240;

Binary Variables  b1,b2,b3,b4,b5,b6,b7,b8,b9,b10,b11,b12,b13,b14,b15,b16,b17
          ,b18,b19,b20,b21,b22,b23,b24,b25,b26,b27,b28,b29,b30,b31,b32,b33,b34
          ,b35,b36,b37,b38,b39,b40,b41,b42,b43,b44,b45,b46,b47,b48,b49,b50,b51
          ,b52,b53,b54,b55,b56,b57,b58,b59,b60,b61,b62,b63,b64,b65,b66,b67,b68
          ,b69,b70,b71,b72,b73,b74,b75,b76,b77,b78,b79,b80,b81,b82,b83,b84,b85
          ,b86,b87,b88,b89,b90,b91,b92,b93,b94,b95,b96;

Equations  e1,e2,e3,e4,e5,e6,e7,e8,e9,e10,e11,e12,e13,e14,e15,e16,e17,e18,e19
          ,e20,e21,e22,e23,e24,e25,e26,e27,e28,e29,e30,e31,e32,e33,e34,e35,e36
          ,e37,e38,e39,e40,e41,e42,e43,e44,e45,e46,e47,e48,e49,e50,e51,e52,e53
          ,e54,e55,e56,e57,e58,e59,e60,e61,e62,e63,e64,e65,e66,e67,e68,e69,e70
          ,e71,e72,e73,e74,e75,e76,e77,e78,e79,e80,e81,e82,e83,e84,e85,e86,e87
          ,e88,e89,e90,e91,e92,e93,e94,e95,e96,e97,e98,e99,e100,e101,e102,e103
          ,e104,e105,e106,e107,e108,e109,e110,e111,e112,e113,e114,e115,e116
          ,e117,e118,e119,e120,e121,e122,e123,e124,e125,e126,e127,e128,e129
          ,e130,e131,e132,e133,e134,e135,e136,e137,e138,e139,e140,e141,e142
          ,e143,e144,e145,e146,e147,e148,e149,e150,e151,e152,e153,e154,e155
          ,e156,e157,e158,e159,e160,e161,e162,e163,e164,e165,e166,e167,e168
          ,e169,e170,e171,e172,e173,e174,e175,e176,e177,e178,e179,e180,e181
          ,e182,e183,e184,e185,e186,e187,e188,e189,e190,e191,e192,e193,e194
          ,e195,e196,e197,e198,e199,e200,e201,e202,e203,e204,e205,e206,e207
          ,e208,e209,e210,e211,e212,e213,e214,e215,e216,e217,e218,e219,e220
          ,e221,e222,e223,e224,e225,e226,e227,e228,e229,e230,e231,e232,e233
          ,e234,e235,e236,e237,e238,e239,e240,e241,e242,e243,e244,e245,e246
          ,e247,e248,e249,e250,e251,e252,e253,e254,e255,e256,e257,e258,e259
          ,e260,e261,e262,e263,e264,e265,e266,e267,e268,e269,e270,e271,e272
          ,e273,e274,e275,e276,e277,e278,e279,e280,e281,e282,e283,e284,e285
          ,e286,e287,e288,e289,e290,e291,e292,e293,e294,e295,e296,e297,e298
          ,e299,e300,e301,e302,e303,e304,e305,e306,e307,e308,e309,e310,e311
          ,e312,e313,e314,e315,e316,e317,e318,e319,e320,e321,e322,e323,e324
          ,e325,e326,e327,e328,e329,e330,e331,e332,e333,e334,e335,e336,e337
          ,e338,e339,e340,e341,e342,e343,e344,e345,e346,e347,e348,e349,e350
          ,e351,e352,e353,e354,e355,e356,e357,e358,e359,e360,e361,e362,e363
          ,e364,e365,e366,e367,e368,e369,e370,e371,e372,e373,e374,e375,e376
          ,e377,e378,e379,e380,e381,e382,e383,e384,e385,e386,e387,e388,e389
          ,e390,e391,e392,e393,e394,e395,e396,e397,e398,e399,e400,e401,e402
          ,e403,e404,e405,e406,e407,e408,e409,e410,e411,e412,e413,e414,e415
          ,e416,e417,e418,e419,e420,e421,e422,e423,e424,e425,e426,e427,e428
          ,e429;


e1..    470.2*b49 + 470.2*b50 + 470.2*b51 + 470.2*b52 + 470.2*b53 + 470.2*b54
      + 470.2*b55 + 470.2*b56 + 470.2*b57 + 470.2*b58 + 470.2*b59 + 470.2*b60
      + 470.2*b61 + 470.2*b62 + 470.2*b63 + 470.2*b64 + 470.2*b65 + 470.2*b66
      + 470.2*b67 + 470.2*b68 + 470.2*b69 + 470.2*b70 + 470.2*b71 + 470.2*b72
      + 592.85*b73 + 592.85*b74 + 592.85*b75 + 592.85*b76 + 592.85*b77
      + 592.85*b78 + 592.85*b79 + 592.85*b80 + 592.85*b81 + 592.85*b82
      + 592.85*b83 + 592.85*b84 + 592.85*b85 + 592.85*b86 + 592.85*b87
      + 592.85*b88 + 592.85*b89 + 592.85*b90 + 592.85*b91 + 592.85*b92
      + 592.85*b93 + 592.85*b94 + 592.85*b95 + 592.85*b96 - 50.4*x97
      - 46.287*x98 - 44.187*x99 - 44.787*x100 - 45.477*x101 - 47.523*x102
      - 58.359*x103 - 68.487*x104 - 87.441*x105 - 91.395*x106 - 93.846*x107
      - 94.995*x108 - 86.187*x109 - 92.295*x110 - 93.495*x111 - 92.259*x112
      - 93.795*x113 - 103.254*x114 - 103.359*x115 - 100.623*x116 - 95.418*x117
      - 92.136*x118 - 82.305*x119 - 68.946*x120 - 50.4*x121 - 46.287*x122
      - 44.187*x123 - 44.787*x124 - 45.477*x125 - 47.523*x126 - 58.359*x127
      - 68.487*x128 - 87.441*x129 - 91.395*x130 - 93.846*x131 - 94.995*x132
      - 86.187*x133 - 92.295*x134 - 93.495*x135 - 92.259*x136 - 93.795*x137
      - 103.254*x138 - 103.359*x139 - 100.623*x140 - 95.418*x141 - 92.136*x142
      - 82.305*x143 - 68.946*x144 + objvar =E= 0;

e2..    x145 + x193 + x241 =E= 10.4208;

e3..    x146 + x194 - x241 + x242 =E= 0.0708;

e4..    x147 + x195 - x242 + x243 =E= 0.0708;

e5..    x148 + x196 - x243 + x244 =E= 0.0708;

e6..    x149 + x197 - x244 + x245 =E= 0.0708;

e7..    x150 + x198 - x245 + x246 =E= 0.0708;

e8..    x151 + x199 - x246 + x247 =E= 0.7374;

e9..    x152 + x200 - x247 + x248 =E= 0.7374;

e10..    x153 + x201 - x248 + x249 =E= 0.7374;

e11..    x154 + x202 - x249 + x250 =E= 0.7374;

e12..    x155 + x203 - x250 + x251 =E= 0.7374;

e13..    x156 + x204 - x251 + x252 =E= 0.7374;

e14..    x157 + x205 - x252 + x253 =E= 0.7374;

e15..    x158 + x206 - x253 + x254 =E= 0.7374;

e16..    x159 + x207 - x254 + x255 =E= 0.7374;

e17..    x160 + x208 - x255 + x256 =E= 0.7374;

e18..    x161 + x209 - x256 + x257 =E= 0.7374;

e19..    x162 + x210 - x257 + x258 =E= 0.7374;

e20..    x163 + x211 - x258 + x259 =E= 0.7374;

e21..    x164 + x212 - x259 + x260 =E= 0.7374;

e22..    x165 + x213 - x260 + x261 =E= 0.7374;

e23..    x166 + x214 - x261 + x262 =E= 0.7374;

e24..    x167 + x215 - x262 + x263 =E= 0.7374;

e25..    x168 + x216 - x263 + x264 =E= 0.7374;

e26..  - x145 + x169 - x193 + x217 + x265 =E= 10.7948;

e27..  - x146 + x170 - x194 + x218 - x265 + x266 =E= 0.1548;

e28..  - x147 + x171 - x195 + x219 - x266 + x267 =E= 0.1548;

e29..  - x148 + x172 - x196 + x220 - x267 + x268 =E= 0.1548;

e30..  - x149 + x173 - x197 + x221 - x268 + x269 =E= 0.1548;

e31..  - x150 + x174 - x198 + x222 - x269 + x270 =E= 0.1548;

e32..  - x151 + x175 - x199 + x223 - x270 + x271 =E= 0.1548;

e33..  - x152 + x176 - x200 + x224 - x271 + x272 =E= 0.1548;

e34..  - x153 + x177 - x201 + x225 - x272 + x273 =E= 0.1548;

e35..  - x154 + x178 - x202 + x226 - x273 + x274 =E= 0.1548;

e36..  - x155 + x179 - x203 + x227 - x274 + x275 =E= 0.1548;

e37..  - x156 + x180 - x204 + x228 - x275 + x276 =E= 0.1548;

e38..  - x157 + x181 - x205 + x229 - x276 + x277 =E= 0.1548;

e39..  - x158 + x182 - x206 + x230 - x277 + x278 =E= 0.1548;

e40..  - x159 + x183 - x207 + x231 - x278 + x279 =E= 0.1548;

e41..  - x160 + x184 - x208 + x232 - x279 + x280 =E= 0.1548;

e42..  - x161 + x185 - x209 + x233 - x280 + x281 =E= 0.1548;

e43..  - x162 + x186 - x210 + x234 - x281 + x282 =E= 0.1548;

e44..  - x163 + x187 - x211 + x235 - x282 + x283 =E= 0.1548;

e45..  - x164 + x188 - x212 + x236 - x283 + x284 =E= 0.1548;

e46..  - x165 + x189 - x213 + x237 - x284 + x285 =E= 0.1548;

e47..  - x166 + x190 - x214 + x238 - x285 + x286 =E= 0.1548;

e48..  - x167 + x191 - x215 + x239 - x286 + x287 =E= 0.1548;

e49..  - x168 + x192 - x216 + x240 - x287 + x288 =E= 0.1548;

e50..  - 4.1202*b1 + x193 =L= 0;

e51..  - 4.1202*b2 + x194 =L= 0;

e52..  - 4.1202*b3 + x195 =L= 0;

e53..  - 4.1202*b4 + x196 =L= 0;

e54..  - 4.1202*b5 + x197 =L= 0;

e55..  - 4.1202*b6 + x198 =L= 0;

e56..  - 4.1202*b7 + x199 =L= 0;

e57..  - 4.1202*b8 + x200 =L= 0;

e58..  - 4.1202*b9 + x201 =L= 0;

e59..  - 4.1202*b10 + x202 =L= 0;

e60..  - 4.1202*b11 + x203 =L= 0;

e61..  - 4.1202*b12 + x204 =L= 0;

e62..  - 4.1202*b13 + x205 =L= 0;

e63..  - 4.1202*b14 + x206 =L= 0;

e64..  - 4.1202*b15 + x207 =L= 0;

e65..  - 4.1202*b16 + x208 =L= 0;

e66..  - 4.1202*b17 + x209 =L= 0;

e67..  - 4.1202*b18 + x210 =L= 0;

e68..  - 4.1202*b19 + x211 =L= 0;

e69..  - 4.1202*b20 + x212 =L= 0;

e70..  - 4.1202*b21 + x213 =L= 0;

e71..  - 4.1202*b22 + x214 =L= 0;

e72..  - 4.1202*b23 + x215 =L= 0;

e73..  - 4.1202*b24 + x216 =L= 0;

e74..  - 3.888*b25 + x217 =L= 0;

e75..  - 3.888*b26 + x218 =L= 0;

e76..  - 3.888*b27 + x219 =L= 0;

e77..  - 3.888*b28 + x220 =L= 0;

e78..  - 3.888*b29 + x221 =L= 0;

e79..  - 3.888*b30 + x222 =L= 0;

e80..  - 3.888*b31 + x223 =L= 0;

e81..  - 3.888*b32 + x224 =L= 0;

e82..  - 3.888*b33 + x225 =L= 0;

e83..  - 3.888*b34 + x226 =L= 0;

e84..  - 3.888*b35 + x227 =L= 0;

e85..  - 3.888*b36 + x228 =L= 0;

e86..  - 3.888*b37 + x229 =L= 0;

e87..  - 3.888*b38 + x230 =L= 0;

e88..  - 3.888*b39 + x231 =L= 0;

e89..  - 3.888*b40 + x232 =L= 0;

e90..  - 3.888*b41 + x233 =L= 0;

e91..  - 3.888*b42 + x234 =L= 0;

e92..  - 3.888*b43 + x235 =L= 0;

e93..  - 3.888*b44 + x236 =L= 0;

e94..  - 3.888*b45 + x237 =L= 0;

e95..  - 3.888*b46 + x238 =L= 0;

e96..  - 3.888*b47 + x239 =L= 0;

e97..  - 3.888*b48 + x240 =L= 0;

e98..  - 0.605268*b1 + x193 =G= 0;

e99..  - 0.605268*b2 + x194 =G= 0;

e100..  - 0.605268*b3 + x195 =G= 0;

e101..  - 0.605268*b4 + x196 =G= 0;

e102..  - 0.605268*b5 + x197 =G= 0;

e103..  - 0.605268*b6 + x198 =G= 0;

e104..  - 0.605268*b7 + x199 =G= 0;

e105..  - 0.605268*b8 + x200 =G= 0;

e106..  - 0.605268*b9 + x201 =G= 0;

e107..  - 0.605268*b10 + x202 =G= 0;

e108..  - 0.605268*b11 + x203 =G= 0;

e109..  - 0.605268*b12 + x204 =G= 0;

e110..  - 0.605268*b13 + x205 =G= 0;

e111..  - 0.605268*b14 + x206 =G= 0;

e112..  - 0.605268*b15 + x207 =G= 0;

e113..  - 0.605268*b16 + x208 =G= 0;

e114..  - 0.605268*b17 + x209 =G= 0;

e115..  - 0.605268*b18 + x210 =G= 0;

e116..  - 0.605268*b19 + x211 =G= 0;

e117..  - 0.605268*b20 + x212 =G= 0;

e118..  - 0.605268*b21 + x213 =G= 0;

e119..  - 0.605268*b22 + x214 =G= 0;

e120..  - 0.605268*b23 + x215 =G= 0;

e121..  - 0.605268*b24 + x216 =G= 0;

e122..  - 0.37692*b25 + x217 =G= 0;

e123..  - 0.37692*b26 + x218 =G= 0;

e124..  - 0.37692*b27 + x219 =G= 0;

e125..  - 0.37692*b28 + x220 =G= 0;

e126..  - 0.37692*b29 + x221 =G= 0;

e127..  - 0.37692*b30 + x222 =G= 0;

e128..  - 0.37692*b31 + x223 =G= 0;

e129..  - 0.37692*b32 + x224 =G= 0;

e130..  - 0.37692*b33 + x225 =G= 0;

e131..  - 0.37692*b34 + x226 =G= 0;

e132..  - 0.37692*b35 + x227 =G= 0;

e133..  - 0.37692*b36 + x228 =G= 0;

e134..  - 0.37692*b37 + x229 =G= 0;

e135..  - 0.37692*b38 + x230 =G= 0;

e136..  - 0.37692*b39 + x231 =G= 0;

e137..  - 0.37692*b40 + x232 =G= 0;

e138..  - 0.37692*b41 + x233 =G= 0;

e139..  - 0.37692*b42 + x234 =G= 0;

e140..  - 0.37692*b43 + x235 =G= 0;

e141..  - 0.37692*b44 + x236 =G= 0;

e142..  - 0.37692*b45 + x237 =G= 0;

e143..  - 0.37692*b46 + x238 =G= 0;

e144..  - 0.37692*b47 + x239 =G= 0;

e145..  - 0.37692*b48 + x240 =G= 0;

e146..  - 28*b1 + x97 =G= 0;

e147..  - 28*b2 + x98 =G= 0;

e148..  - 28*b3 + x99 =G= 0;

e149..  - 28*b4 + x100 =G= 0;

e150..  - 28*b5 + x101 =G= 0;

e151..  - 28*b6 + x102 =G= 0;

e152..  - 28*b7 + x103 =G= 0;

e153..  - 28*b8 + x104 =G= 0;

e154..  - 28*b9 + x105 =G= 0;

e155..  - 28*b10 + x106 =G= 0;

e156..  - 28*b11 + x107 =G= 0;

e157..  - 28*b12 + x108 =G= 0;

e158..  - 28*b13 + x109 =G= 0;

e159..  - 28*b14 + x110 =G= 0;

e160..  - 28*b15 + x111 =G= 0;

e161..  - 28*b16 + x112 =G= 0;

e162..  - 28*b17 + x113 =G= 0;

e163..  - 28*b18 + x114 =G= 0;

e164..  - 28*b19 + x115 =G= 0;

e165..  - 28*b20 + x116 =G= 0;

e166..  - 28*b21 + x117 =G= 0;

e167..  - 28*b22 + x118 =G= 0;

e168..  - 28*b23 + x119 =G= 0;

e169..  - 28*b24 + x120 =G= 0;

e170..  - 29.99*b25 + x121 =G= 0;

e171..  - 29.99*b26 + x122 =G= 0;

e172..  - 29.99*b27 + x123 =G= 0;

e173..  - 29.99*b28 + x124 =G= 0;

e174..  - 29.99*b29 + x125 =G= 0;

e175..  - 29.99*b30 + x126 =G= 0;

e176..  - 29.99*b31 + x127 =G= 0;

e177..  - 29.99*b32 + x128 =G= 0;

e178..  - 29.99*b33 + x129 =G= 0;

e179..  - 29.99*b34 + x130 =G= 0;

e180..  - 29.99*b35 + x131 =G= 0;

e181..  - 29.99*b36 + x132 =G= 0;

e182..  - 29.99*b37 + x133 =G= 0;

e183..  - 29.99*b38 + x134 =G= 0;

e184..  - 29.99*b39 + x135 =G= 0;

e185..  - 29.99*b40 + x136 =G= 0;

e186..  - 29.99*b41 + x137 =G= 0;

e187..  - 29.99*b42 + x138 =G= 0;

e188..  - 29.99*b43 + x139 =G= 0;

e189..  - 29.99*b44 + x140 =G= 0;

e190..  - 29.99*b45 + x141 =G= 0;

e191..  - 29.99*b46 + x142 =G= 0;

e192..  - 29.99*b47 + x143 =G= 0;

e193..  - 29.99*b48 + x144 =G= 0;

e194..  - 188.08*b1 + x97 =L= 0;

e195..  - 188.08*b2 + x98 =L= 0;

e196..  - 188.08*b3 + x99 =L= 0;

e197..  - 188.08*b4 + x100 =L= 0;

e198..  - 188.08*b5 + x101 =L= 0;

e199..  - 188.08*b6 + x102 =L= 0;

e200..  - 188.08*b7 + x103 =L= 0;

e201..  - 188.08*b8 + x104 =L= 0;

e202..  - 188.08*b9 + x105 =L= 0;

e203..  - 188.08*b10 + x106 =L= 0;

e204..  - 188.08*b11 + x107 =L= 0;

e205..  - 188.08*b12 + x108 =L= 0;

e206..  - 188.08*b13 + x109 =L= 0;

e207..  - 188.08*b14 + x110 =L= 0;

e208..  - 188.08*b15 + x111 =L= 0;

e209..  - 188.08*b16 + x112 =L= 0;

e210..  - 188.08*b17 + x113 =L= 0;

e211..  - 188.08*b18 + x114 =L= 0;

e212..  - 188.08*b19 + x115 =L= 0;

e213..  - 188.08*b20 + x116 =L= 0;

e214..  - 188.08*b21 + x117 =L= 0;

e215..  - 188.08*b22 + x118 =L= 0;

e216..  - 188.08*b23 + x119 =L= 0;

e217..  - 188.08*b24 + x120 =L= 0;

e218..  - 237.14*b25 + x121 =L= 0;

e219..  - 237.14*b26 + x122 =L= 0;

e220..  - 237.14*b27 + x123 =L= 0;

e221..  - 237.14*b28 + x124 =L= 0;

e222..  - 237.14*b29 + x125 =L= 0;

e223..  - 237.14*b30 + x126 =L= 0;

e224..  - 237.14*b31 + x127 =L= 0;

e225..  - 237.14*b32 + x128 =L= 0;

e226..  - 237.14*b33 + x129 =L= 0;

e227..  - 237.14*b34 + x130 =L= 0;

e228..  - 237.14*b35 + x131 =L= 0;

e229..  - 237.14*b36 + x132 =L= 0;

e230..  - 237.14*b37 + x133 =L= 0;

e231..  - 237.14*b38 + x134 =L= 0;

e232..  - 237.14*b39 + x135 =L= 0;

e233..  - 237.14*b40 + x136 =L= 0;

e234..  - 237.14*b41 + x137 =L= 0;

e235..  - 237.14*b42 + x138 =L= 0;

e236..  - 237.14*b43 + x139 =L= 0;

e237..  - 237.14*b44 + x140 =L= 0;

e238..  - 237.14*b45 + x141 =L= 0;

e239..  - 237.14*b46 + x142 =L= 0;

e240..  - 237.14*b47 + x143 =L= 0;

e241..  - 237.14*b48 + x144 =L= 0;

e242..    x193 - x194 =L= 2.0601;

e243..    x194 - x195 =L= 2.0601;

e244..    x195 - x196 =L= 2.0601;

e245..    x196 - x197 =L= 2.0601;

e246..    x197 - x198 =L= 2.0601;

e247..    x198 - x199 =L= 2.0601;

e248..    x199 - x200 =L= 2.0601;

e249..    x200 - x201 =L= 2.0601;

e250..    x201 - x202 =L= 2.0601;

e251..    x202 - x203 =L= 2.0601;

e252..    x203 - x204 =L= 2.0601;

e253..    x204 - x205 =L= 2.0601;

e254..    x205 - x206 =L= 2.0601;

e255..    x206 - x207 =L= 2.0601;

e256..    x207 - x208 =L= 2.0601;

e257..    x208 - x209 =L= 2.0601;

e258..    x209 - x210 =L= 2.0601;

e259..    x210 - x211 =L= 2.0601;

e260..    x211 - x212 =L= 2.0601;

e261..    x212 - x213 =L= 2.0601;

e262..    x213 - x214 =L= 2.0601;

e263..    x214 - x215 =L= 2.0601;

e264..    x215 - x216 =L= 2.0601;

e265..    x217 - x218 =L= 1.944;

e266..    x218 - x219 =L= 1.944;

e267..    x219 - x220 =L= 1.944;

e268..    x220 - x221 =L= 1.944;

e269..    x221 - x222 =L= 1.944;

e270..    x222 - x223 =L= 1.944;

e271..    x223 - x224 =L= 1.944;

e272..    x224 - x225 =L= 1.944;

e273..    x225 - x226 =L= 1.944;

e274..    x226 - x227 =L= 1.944;

e275..    x227 - x228 =L= 1.944;

e276..    x228 - x229 =L= 1.944;

e277..    x229 - x230 =L= 1.944;

e278..    x230 - x231 =L= 1.944;

e279..    x231 - x232 =L= 1.944;

e280..    x232 - x233 =L= 1.944;

e281..    x233 - x234 =L= 1.944;

e282..    x234 - x235 =L= 1.944;

e283..    x235 - x236 =L= 1.944;

e284..    x236 - x237 =L= 1.944;

e285..    x237 - x238 =L= 1.944;

e286..    x238 - x239 =L= 1.944;

e287..    x239 - x240 =L= 1.944;

e288..  - x193 + x194 =L= 2.0601;

e289..  - x194 + x195 =L= 2.0601;

e290..  - x195 + x196 =L= 2.0601;

e291..  - x196 + x197 =L= 2.0601;

e292..  - x197 + x198 =L= 2.0601;

e293..  - x198 + x199 =L= 2.0601;

e294..  - x199 + x200 =L= 2.0601;

e295..  - x200 + x201 =L= 2.0601;

e296..  - x201 + x202 =L= 2.0601;

e297..  - x202 + x203 =L= 2.0601;

e298..  - x203 + x204 =L= 2.0601;

e299..  - x204 + x205 =L= 2.0601;

e300..  - x205 + x206 =L= 2.0601;

e301..  - x206 + x207 =L= 2.0601;

e302..  - x207 + x208 =L= 2.0601;

e303..  - x208 + x209 =L= 2.0601;

e304..  - x209 + x210 =L= 2.0601;

e305..  - x210 + x211 =L= 2.0601;

e306..  - x211 + x212 =L= 2.0601;

e307..  - x212 + x213 =L= 2.0601;

e308..  - x213 + x214 =L= 2.0601;

e309..  - x214 + x215 =L= 2.0601;

e310..  - x215 + x216 =L= 2.0601;

e311..  - x217 + x218 =L= 1.944;

e312..  - x218 + x219 =L= 1.944;

e313..  - x219 + x220 =L= 1.944;

e314..  - x220 + x221 =L= 1.944;

e315..  - x221 + x222 =L= 1.944;

e316..  - x222 + x223 =L= 1.944;

e317..  - x223 + x224 =L= 1.944;

e318..  - x224 + x225 =L= 1.944;

e319..  - x225 + x226 =L= 1.944;

e320..  - x226 + x227 =L= 1.944;

e321..  - x227 + x228 =L= 1.944;

e322..  - x228 + x229 =L= 1.944;

e323..  - x229 + x230 =L= 1.944;

e324..  - x230 + x231 =L= 1.944;

e325..  - x231 + x232 =L= 1.944;

e326..  - x232 + x233 =L= 1.944;

e327..  - x233 + x234 =L= 1.944;

e328..  - x234 + x235 =L= 1.944;

e329..  - x235 + x236 =L= 1.944;

e330..  - x236 + x237 =L= 1.944;

e331..  - x237 + x238 =L= 1.944;

e332..  - x238 + x239 =L= 1.944;

e333..  - x239 + x240 =L= 1.944;

e334..  - b1 + b49 =G= 0;

e335..    b1 - b2 + b50 =G= 0;

e336..    b2 - b3 + b51 =G= 0;

e337..    b3 - b4 + b52 =G= 0;

e338..    b4 - b5 + b53 =G= 0;

e339..    b5 - b6 + b54 =G= 0;

e340..    b6 - b7 + b55 =G= 0;

e341..    b7 - b8 + b56 =G= 0;

e342..    b8 - b9 + b57 =G= 0;

e343..    b9 - b10 + b58 =G= 0;

e344..    b10 - b11 + b59 =G= 0;

e345..    b11 - b12 + b60 =G= 0;

e346..    b12 - b13 + b61 =G= 0;

e347..    b13 - b14 + b62 =G= 0;

e348..    b14 - b15 + b63 =G= 0;

e349..    b15 - b16 + b64 =G= 0;

e350..    b16 - b17 + b65 =G= 0;

e351..    b17 - b18 + b66 =G= 0;

e352..    b18 - b19 + b67 =G= 0;

e353..    b19 - b20 + b68 =G= 0;

e354..    b20 - b21 + b69 =G= 0;

e355..    b21 - b22 + b70 =G= 0;

e356..    b22 - b23 + b71 =G= 0;

e357..    b23 - b24 + b72 =G= 0;

e358..  - b25 + b73 =G= 0;

e359..    b25 - b26 + b74 =G= 0;

e360..    b26 - b27 + b75 =G= 0;

e361..    b27 - b28 + b76 =G= 0;

e362..    b28 - b29 + b77 =G= 0;

e363..    b29 - b30 + b78 =G= 0;

e364..    b30 - b31 + b79 =G= 0;

e365..    b31 - b32 + b80 =G= 0;

e366..    b32 - b33 + b81 =G= 0;

e367..    b33 - b34 + b82 =G= 0;

e368..    b34 - b35 + b83 =G= 0;

e369..    b35 - b36 + b84 =G= 0;

e370..    b36 - b37 + b85 =G= 0;

e371..    b37 - b38 + b86 =G= 0;

e372..    b38 - b39 + b87 =G= 0;

e373..    b39 - b40 + b88 =G= 0;

e374..    b40 - b41 + b89 =G= 0;

e375..    b41 - b42 + b90 =G= 0;

e376..    b42 - b43 + b91 =G= 0;

e377..    b43 - b44 + b92 =G= 0;

e378..    b44 - b45 + b93 =G= 0;

e379..    b45 - b46 + b94 =G= 0;

e380..    b46 - b47 + b95 =G= 0;

e381..    b47 - b48 + b96 =G= 0;

e382.. -(0.5061084326298*x193*x241 + 50.09702*x193 - 0.5580651303227*x265*x193)
        + x97 =E= 0;

e383.. -(0.5061084326298*x194*x242 + 50.09702*x194 - 0.5580651303227*x266*x194)
        + x98 =E= 0;

e384.. -(0.5061084326298*x195*x243 + 50.09702*x195 - 0.5580651303227*x267*x195)
        + x99 =E= 0;

e385.. -(0.5061084326298*x196*x244 + 50.09702*x196 - 0.5580651303227*x268*x196)
        + x100 =E= 0;

e386.. -(0.5061084326298*x197*x245 + 50.09702*x197 - 0.5580651303227*x269*x197)
        + x101 =E= 0;

e387.. -(0.5061084326298*x198*x246 + 50.09702*x198 - 0.5580651303227*x270*x198)
        + x102 =E= 0;

e388.. -(0.5061084326298*x199*x247 + 50.09702*x199 - 0.5580651303227*x271*x199)
        + x103 =E= 0;

e389.. -(0.5061084326298*x200*x248 + 50.09702*x200 - 0.5580651303227*x272*x200)
        + x104 =E= 0;

e390.. -(0.5061084326298*x201*x249 + 50.09702*x201 - 0.5580651303227*x273*x201)
        + x105 =E= 0;

e391.. -(0.5061084326298*x202*x250 + 50.09702*x202 - 0.5580651303227*x274*x202)
        + x106 =E= 0;

e392.. -(0.5061084326298*x203*x251 + 50.09702*x203 - 0.5580651303227*x275*x203)
        + x107 =E= 0;

e393.. -(0.5061084326298*x204*x252 + 50.09702*x204 - 0.5580651303227*x276*x204)
        + x108 =E= 0;

e394.. -(0.5061084326298*x205*x253 + 50.09702*x205 - 0.5580651303227*x277*x205)
        + x109 =E= 0;

e395.. -(0.5061084326298*x206*x254 + 50.09702*x206 - 0.5580651303227*x278*x206)
        + x110 =E= 0;

e396.. -(0.5061084326298*x207*x255 + 50.09702*x207 - 0.5580651303227*x279*x207)
        + x111 =E= 0;

e397.. -(0.5061084326298*x208*x256 + 50.09702*x208 - 0.5580651303227*x280*x208)
        + x112 =E= 0;

e398.. -(0.5061084326298*x209*x257 + 50.09702*x209 - 0.5580651303227*x281*x209)
        + x113 =E= 0;

e399.. -(0.5061084326298*x210*x258 + 50.09702*x210 - 0.5580651303227*x282*x210)
        + x114 =E= 0;

e400.. -(0.5061084326298*x211*x259 + 50.09702*x211 - 0.5580651303227*x283*x211)
        + x115 =E= 0;

e401.. -(0.5061084326298*x212*x260 + 50.09702*x212 - 0.5580651303227*x284*x212)
        + x116 =E= 0;

e402.. -(0.5061084326298*x213*x261 + 50.09702*x213 - 0.5580651303227*x285*x213)
        + x117 =E= 0;

e403.. -(0.5061084326298*x214*x262 + 50.09702*x214 - 0.5580651303227*x286*x214)
        + x118 =E= 0;

e404.. -(0.5061084326298*x215*x263 + 50.09702*x215 - 0.5580651303227*x287*x215)
        + x119 =E= 0;

e405.. -(0.5061084326298*x216*x264 + 50.09702*x216 - 0.5580651303227*x288*x216)
        + x120 =E= 0;

e406.. -(0.5623466695665*x217*x265 + 78.54163*x217) + x121 =E= 0;

e407.. -(0.5623466695665*x218*x266 + 78.54163*x218) + x122 =E= 0;

e408.. -(0.5623466695665*x219*x267 + 78.54163*x219) + x123 =E= 0;

e409.. -(0.5623466695665*x220*x268 + 78.54163*x220) + x124 =E= 0;

e410.. -(0.5623466695665*x221*x269 + 78.54163*x221) + x125 =E= 0;

e411.. -(0.5623466695665*x222*x270 + 78.54163*x222) + x126 =E= 0;

e412.. -(0.5623466695665*x223*x271 + 78.54163*x223) + x127 =E= 0;

e413.. -(0.5623466695665*x224*x272 + 78.54163*x224) + x128 =E= 0;

e414.. -(0.5623466695665*x225*x273 + 78.54163*x225) + x129 =E= 0;

e415.. -(0.5623466695665*x226*x274 + 78.54163*x226) + x130 =E= 0;

e416.. -(0.5623466695665*x227*x275 + 78.54163*x227) + x131 =E= 0;

e417.. -(0.5623466695665*x228*x276 + 78.54163*x228) + x132 =E= 0;

e418.. -(0.5623466695665*x229*x277 + 78.54163*x229) + x133 =E= 0;

e419.. -(0.5623466695665*x230*x278 + 78.54163*x230) + x134 =E= 0;

e420.. -(0.5623466695665*x231*x279 + 78.54163*x231) + x135 =E= 0;

e421.. -(0.5623466695665*x232*x280 + 78.54163*x232) + x136 =E= 0;

e422.. -(0.5623466695665*x233*x281 + 78.54163*x233) + x137 =E= 0;

e423.. -(0.5623466695665*x234*x282 + 78.54163*x234) + x138 =E= 0;

e424.. -(0.5623466695665*x235*x283 + 78.54163*x235) + x139 =E= 0;

e425.. -(0.5623466695665*x236*x284 + 78.54163*x236) + x140 =E= 0;

e426.. -(0.5623466695665*x237*x285 + 78.54163*x237) + x141 =E= 0;

e427.. -(0.5623466695665*x238*x286 + 78.54163*x238) + x142 =E= 0;

e428.. -(0.5623466695665*x239*x287 + 78.54163*x239) + x143 =E= 0;

e429.. -(0.5623466695665*x240*x288 + 78.54163*x240) + x144 =E= 0;

* set non-default bounds
x97.up = 188.08;
x98.up = 188.08;
x99.up = 188.08;
x100.up = 188.08;
x101.up = 188.08;
x102.up = 188.08;
x103.up = 188.08;
x104.up = 188.08;
x105.up = 188.08;
x106.up = 188.08;
x107.up = 188.08;
x108.up = 188.08;
x109.up = 188.08;
x110.up = 188.08;
x111.up = 188.08;
x112.up = 188.08;
x113.up = 188.08;
x114.up = 188.08;
x115.up = 188.08;
x116.up = 188.08;
x117.up = 188.08;
x118.up = 188.08;
x119.up = 188.08;
x120.up = 188.08;
x121.up = 237.14;
x122.up = 237.14;
x123.up = 237.14;
x124.up = 237.14;
x125.up = 237.14;
x126.up = 237.14;
x127.up = 237.14;
x128.up = 237.14;
x129.up = 237.14;
x130.up = 237.14;
x131.up = 237.14;
x132.up = 237.14;
x133.up = 237.14;
x134.up = 237.14;
x135.up = 237.14;
x136.up = 237.14;
x137.up = 237.14;
x138.up = 237.14;
x139.up = 237.14;
x140.up = 237.14;
x141.up = 237.14;
x142.up = 237.14;
x143.up = 237.14;
x144.up = 237.14;
x193.up = 4.1202;
x194.up = 4.1202;
x195.up = 4.1202;
x196.up = 4.1202;
x197.up = 4.1202;
x198.up = 4.1202;
x199.up = 4.1202;
x200.up = 4.1202;
x201.up = 4.1202;
x202.up = 4.1202;
x203.up = 4.1202;
x204.up = 4.1202;
x205.up = 4.1202;
x206.up = 4.1202;
x207.up = 4.1202;
x208.up = 4.1202;
x209.up = 4.1202;
x210.up = 4.1202;
x211.up = 4.1202;
x212.up = 4.1202;
x213.up = 4.1202;
x214.up = 4.1202;
x215.up = 4.1202;
x216.up = 4.1202;
x217.up = 3.888;
x218.up = 3.888;
x219.up = 3.888;
x220.up = 3.888;
x221.up = 3.888;
x222.up = 3.888;
x223.up = 3.888;
x224.up = 3.888;
x225.up = 3.888;
x226.up = 3.888;
x227.up = 3.888;
x228.up = 3.888;
x229.up = 3.888;
x230.up = 3.888;
x231.up = 3.888;
x232.up = 3.888;
x233.up = 3.888;
x234.up = 3.888;
x235.up = 3.888;
x236.up = 3.888;
x237.up = 3.888;
x238.up = 3.888;
x239.up = 3.888;
x240.up = 3.888;
x241.lo = 5.18; x241.up = 12.94;
x242.lo = 5.18; x242.up = 12.94;
x243.lo = 5.18; x243.up = 12.94;
x244.lo = 5.18; x244.up = 12.94;
x245.lo = 5.18; x245.up = 12.94;
x246.lo = 5.18; x246.up = 12.94;
x247.lo = 5.18; x247.up = 12.94;
x248.lo = 5.18; x248.up = 12.94;
x249.lo = 5.18; x249.up = 12.94;
x250.lo = 5.18; x250.up = 12.94;
x251.lo = 5.18; x251.up = 12.94;
x252.lo = 5.18; x252.up = 12.94;
x253.lo = 5.18; x253.up = 12.94;
x254.lo = 5.18; x254.up = 12.94;
x255.lo = 5.18; x255.up = 12.94;
x256.lo = 5.18; x256.up = 12.94;
x257.lo = 5.18; x257.up = 12.94;
x258.lo = 5.18; x258.up = 12.94;
x259.lo = 5.18; x259.up = 12.94;
x260.lo = 5.18; x260.up = 12.94;
x261.lo = 5.18; x261.up = 12.94;
x262.lo = 5.18; x262.up = 12.94;
x263.lo = 5.18; x263.up = 12.94;
x264.fx = 10.35;
x265.lo = 5.32; x265.up = 13.3;
x266.lo = 5.32; x266.up = 13.3;
x267.lo = 5.32; x267.up = 13.3;
x268.lo = 5.32; x268.up = 13.3;
x269.lo = 5.32; x269.up = 13.3;
x270.lo = 5.32; x270.up = 13.3;
x271.lo = 5.32; x271.up = 13.3;
x272.lo = 5.32; x272.up = 13.3;
x273.lo = 5.32; x273.up = 13.3;
x274.lo = 5.32; x274.up = 13.3;
x275.lo = 5.32; x275.up = 13.3;
x276.lo = 5.32; x276.up = 13.3;
x277.lo = 5.32; x277.up = 13.3;
x278.lo = 5.32; x278.up = 13.3;
x279.lo = 5.32; x279.up = 13.3;
x280.lo = 5.32; x280.up = 13.3;
x281.lo = 5.32; x281.up = 13.3;
x282.lo = 5.32; x282.up = 13.3;
x283.lo = 5.32; x283.up = 13.3;
x284.lo = 5.32; x284.up = 13.3;
x285.lo = 5.32; x285.up = 13.3;
x286.lo = 5.32; x286.up = 13.3;
x287.lo = 5.32; x287.up = 13.3;
x288.fx = 10.64;

Model m / all /;

m.limrow=0; m.limcol=0;
m.tolproj=0.0;

$if NOT '%gams.u1%' == '' $include '%gams.u1%'

$if not set MINLP $set MINLP MINLP
Solve m using %MINLP% maximizing objvar;


Last updated: 2018-09-14 Git hash: ac5a5314
Imprint / Privacy Policy
